Brauer Medium & Light Castors

Range: Castor: Group : LG Series - Max Load (600kg)
If enabled click on ´Wheel Data´ to view wheel specification.									<< Back
Part No	Mount	Wheel Ø (A)	Overall Height (B)	Tread Width (C)	Swivel Radius (F)	Max Load Rating	Wheel Bearing Type	Castor Weight (kg)	Wheel Data
LGS/H150/35BJ	Swivel	150	200	35	122	600	BJ	8	H150/35
LGF/H150/35BJ	Fixed	150	200	35	n/a	600	BJ	8	H150/35
LGS/H125/45BJ	Swivel	125	110	45	187.5	600	BJ	7	H125/45
LGF/H125/45BJ	Fixed	125	110	45	n/a	600	BJ	7	H125/45
LGS/H125/30BJ	Swivel	125	110	30	187.5	400	BJ	7	H125/30
LGF/H125/30BJ	Fixed	125	110	30	n/a	400	BJ	7	H125/30
Top plates have fixing holes to suit 10mm diameter bolts Swivel top plate thickness 6mm Fixed top plate thickness 6mm For technical information covering load factors, etc., see Design Data
