StandardRange: Airmovers:
Group: Standard Fixed Gap
Product: AM125

Technical details.

<< Back

Material: Aluminium alloy
Weight: 7.55kg
Standard Gap: 0.15mm
DBA at: 5.5 bar is 85
Shims: Not required
Optional Extra
Standard Inlet Threads: 3/4" BSP
Options: 3/4" NPT
Please specify on order 3/4" NPTF
Bar Vol in m³ /min Vol out m³ /min
1.38 1.982 38.936
2.76 3.115 53.66
4.14 4.276 68.668
5.52 5.324 80.137






am125
